Low Noise Industrial Tray Dryer Hot Air Circulation Oven 30KW 45KW

Brand Name : shinma

Model Number : CT-C-1

Certification : ISO9001,ISO14001

Place of Origin : changzhou

MOQ : 1set

Price : USD15000-60000/set

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 30sets

Delivery Time : 60days

Packaging Details : nacked packing

Applicable Industries : Food & Beverage Factory, Fruit and vegetable processing machinery

Type : Dryer

Voltage : 380V

Power : 9.5KW

Dimension(L*W*H) : 6000*2800*2200MM

Product name : industrial food dryer

Material : Stainless steel

Energy : Energy saving

Application : Drying fruit&vegetables&seafood

Contact Now

Horizontal Drying Oven – Hot Air Circulation, High Efficiency, Wide Application, Low Noise Dryer

What Are DRYTECH Heat Pump Drying Machine?

DRYTECH Heat Pump Drying Machine takes advantage of the reversed Carnot principle, absorbing the heat from around and sending the heat to the materials which will be dried. This kind of dryer is mainly composed of heat pump dryer and drying chamber. This dryer will be controlled by touch screen controller, and the temperature can be adjusted. It has low electric consumption.

1. Most of hot air is circled inside the oven. The hot efficiency is highThe energy source can be saved.

2. Enhanced ventilation is used and it is equipped with adjustable airdivider plate inside the oven. Raw materials can be dried evenly. Thehot sources can be steam, hot water, electricity of far infrared.

3. The machine has low noise and stable operation. The temperaturecan be controlled automatically. The installation and maintenanceare very convenient.
4. The applied fields are wide and can be suitable for all kinds of rawmaterials,It is a comprehensive drier

Model
CT- C-0
CT- C- IA
CT-C-I
CT-C-II
CT- C-III
CT- C-IV
Drying capacity
(kg)
25
50
100
200
300
400
Heating power
(kw)
9
12
15
30
45
60
Steam heating area(m²)
10
15
20
40
80
100
Blowing rate
(m3/h)
3400
3400
3450
6900
10350
13800
Drying tray
(pcs)
16
24
48
96
144
192
Length × width × height (m)
1.4x1.2x1.6
1.4x1.2x2.0
2.3x1.2x2.0
2.3x2.2x2.0
2.3x3.22x2.0
4.45x2.2x2.0
Trolley
1
1
2
4
6
8

Model Evaporated area(m²)

Effective volume

((m³)

Capacity

(kg/batch)

Radiator Area

(m²)

 Steam (kg/h) Electric Power (kw) Fan Power (kw)

Overall

(mm)

Weight

(kg)
CT-C-0 7.1 1.3 60 15 15 6-9 0.45

1380×12

00×2000

 820
CT-C-Ⅰ 14.1 2.6 120 23 20 15 0.45

2360×12

00×2000

 1580
CT-C-Ⅱ 28.3 4.9 240 48 40 30 0.45 ×2

2260×22

00×2000

 1800
CT-C-Ⅲ 42.4 7.4 360 72 60 45 0.45×3

3240 ×22

00 ×2000

 2210
CT-C-IV 56.5 10.3 500 96 80 60 0.45×4

4280 ×22

00×2770

 2800
